Converter DC 12V 24V 48V to AC 110V 120V 220V 230V 240V

Get the best quality Converter DC 12V 24V 48V to AC 110V 120V 220V 230V 240V from our factory. Trust our expertise for reliable power conversion solutions.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
REP300
Nature of Wave String
Sine Wave Inverter
Type
DC/AC Inverters
Application
Electric Tools
Warranty
24 Months
OEM/ODM
Accepted
Shell Material
Aluminum Alloy
Color
Can Be Customized
Input Voltage
12V or 24V or 48V
Output Voltage
110V or 220V
Transport Package
Paper Box
Specification
165x115x60mm
Trademark
ROGERELE
Origin
Zhejiang
HS Code
8504403090

Product Description

Converter DC 12V 24V 48V to AC 110V 120V 220V 230V 240V
Converter DC 12V 24V 48V to AC 110V 120V 220V 230V 240V
Model REP300-121 REP300-241 REP300-481 REP300-122 REP300-242 REP300-482
Rated power 300W
Peak power 600W
Input voltage DC12V DC24V DC48V DC12V DC24V DC48V
Output voltage 100VAC or 110VAC or 120VAC±5% 220VAC or 230VAC or 240VAC±5%
Unload current less than 0.3A 0.2A 0.2A 0.3A 0.2A 0.2A
Output frequency 50Hz±0.5Hz or 60Hz±0.5Hz
Output waveform Pure Sine Wave
Waveform distortion THD<3%(Linear load)
USB port 5V 1A
Max.efficiency 90%
Input voltage range 10-15.5V 20-31V 40-61V 10-15.5V 20-31V 40-61V
Low voltage alarm 10.5±0.5V 21±0.5V 42±1V 10.5±0.5V 21±0.5V 42±1V
Low voltage protection 10±0.5V 20±0.5V 40±15V 10±0.5V 20±0.5V 40±15V
Over voltage protection 15.5±0.5V 31±0.5V 61±1V 15.5±0.5V 31±0.5V 61±1V
Low voltage recover 13±0.5V 24±0.5V 48±1V 13±0.5V 24±0.5V 48±1V
Over voltage recover 14.8V±0.5V 29.5V±0.5V 59V±1V 14.8V±0.5V 29.5V±0.5V 59V±1V
Working temperature -10°- +50°
Storage temperature -30°- +70°
Dimension(mm) 165x115x60mm
Packing(mm) 235x145x73mm
Net./gross weight(g) 850g/1020g
QTY/Ctn 15 Pcs
Meas./Ctn(mm) 460x390x255mm
Gross weight/Ctn(g) 15500g
Warranty 2 years
Configuration Standard
Cooling method Intelligent air cooling
Custom-made available:
Except for the regular DC input voltages: 12V, 24V, 48V, we also could provide customized DC input voltages: DC 36V,DC 60V,DC 72V,DC 84V,DC 96V...


Converter DC 12V 24V 48V to AC 110V 120V 220V 230V 240V


Converter DC 12V 24V 48V to AC 110V 120V 220V 230V 240V

Converter DC 12V 24V 48V to AC 110V 120V 220V 230V 240V
Converter DC 12V 24V 48V to AC 110V 120V 220V 230V 240V
Converter DC 12V 24V 48V to AC 110V 120V 220V 230V 240V
Converter DC 12V 24V 48V to AC 110V 120V 220V 230V 240V
Converter DC 12V 24V 48V to AC 110V 120V 220V 230V 240V

1.Do you have you own factory?

A:Yes,we are professional manufacturer mainly in power inverter for about 10 years.Our factory is located in Yueqing,Zhejiang,China.
..............................................................................................................................................................
2,Q:Why your quotation is higher than other suppliers?
A:In domestic market, the high and low inverter brands are mixed together. There are many low-cost inverter is actually some assembled small unlicensed workshops, it crudely, to reduce costs and use of substandard components for assembly, there is a very big security risk! In order to protect the pro personal and property safety, please do not covet low price, be sure to choose a reliable inverter!
..............................................................................................................................................................
3,Q:How many categories does it have according to the output waveform ?
A:Type one: REM Modified Sine Wave inverter, which uses PWM pulse width modulation to generate modified sine wave. Due to the usage of intelligent dedicated circuit and high power field effect tube, it greatly reduces the power loss and increases the soft-start function, effectively ensuring the reliability of the inverter. If the power quality is not highly demanded, it is able to meet the needs of most electrical equipment. But it still exists 20% harmonic distortion problems when running sophisticated quipment, can also cause high-frequency interference to radio communications equipment. This kind of inverter can meet the basic needs of most of our power, high efficiency, small noise, moderate price, and thus become the mainstream products in the market
   Type two: REP Pure Sine Wave inverter, which adopts isolated coupling circuit design, high efficiency, high stability of the output waveform, high-frequency technology, small in size, suitable for all kinds of load, can be connected to any common electrical devices and inductive load devices (such as refrigerators, electric drill, etc.) without any interference (eg: buzz and TV noise). The output of pure sine wave inverter is the same as the grid tie power we daily used, or even better, because it does not exist grid tie electromagnetic pollution.
.....................................................................................................................
4,Q:What is a resistive load appliances?
A:Generally speaking, appliances like mobile phones, computers, LCD TVs, incandescents, electric fans, video broadcast, small printers, electric mahjong machines, rice cookers etc. All belong to resistive loads. Our modified sine wave inverters can drive them successfully.
..............................................................................................................................................................
5,Q:What is the inductive load appliances?
A:It refers to the application of electromagnetic induction's principle, produced by high-power electrical products, such as motor type, compressors, relays, fluorescent lamps, electric stove, refrigerator, air conditioner, energy saving lamps, pumps, etc. These products'power are far more than the rated power (about 3-7 times) when start. So only pure sine wave inverter is available to them.
.....................................................................................................................
6. Q : Can you make customized products and customized packing?
A: Yes.We made a lot of customized products for our customer before.
And we made many moulds for our customers alread.
About customized packing,we can put your Logo or other info on the packing.
